BC-U2 Universal Lithium Battery Charger with USB Output & Car Charger for 14500 14650 17670 18500 18650 18700 10440 16340 S-LIB-0002

Product Code: S-LIB-0002
Availability: Yes
RM124.90
Buy Now

Qty

Information:

Quantity (Any Items)
Discount
2
Free Shipping
3-9
-5% + Free Shipping
10-19
-10% + Free Shipping
=>20
Contact us
Free Shipping = Minimum Qty 2 & Total amount >=RM50

Processing & Shipping Time : 2~8 Working days



Description

1) Charging qualifications and structures

2) Operation Temperature: 0~40?

3) Input AC: 12V DC: 1000mA

4) 500mA CC Current: 500m A±5%

5) 1000 A CC Current: 1000m A±5%

6) Cut-Off Voltage: 4.2±0.05V

7) CV Cut-off Current: ?100mA

8) Standby Current: ?20.0m A

9) TC Current (Battery Volt 2.0~3.0V): 80±20m A

10) Auto Recharging Threshold Value Voltage: 3.9±0.15V

11) USB Discharging qualifications and structures

12) Operation Temperature: 0~40?

13) USB Interface Output Floating Voltage: 5.0V

14) Output Floating Voltage Ripple: ?120 mV

15) Reactive Current: ?10m A

16) Maximum Output Current: 500mA

17) Battery Output Cut-off Voltage: 2.80±0.15V

18) XTAR WP2II charger is apply to 14500/17670/18500/18650/18700 and 10440/16340 li-ion battery when use 2pcs spacers simultaneously but independently.

19) It built USB output function can supply electricity to those devices power below 5.0V/500mA

20) WP2II designed with undervoltage lockout,algorithm(TC.CC.CV)charging method,reverse-polarity protection circuit board,over/under voltage disconnecting technology and battery over discharging activating fucntion,it is a intelligent and your first choice safer and reliable li-ion battery charger.

21) USB interface output floating voltage: 5.0V

22) Maximum output current: 500mA

23) Size: 113x47x32mm

24) 0 Gear: USB 5.0V/500mA voltage output

-1 Gear: charging current 500mA

-2 Gear: charging current 1000mA

Warranty : 3 Months

Package Includes :
1 x BC-U2 Universal Lithium Battery Charger with USB Output & Car Charger for 14500 / 14650 / 17670 / 18500 / 18650 / 18700 / 10440 / 16340
